Key Features
- 2500mAh lithium-ion capacity for reliable runtime
- High 20A maximum continuous discharge capability
- Flat top 18650 format for pack and device integration
- Stable IMR chemistry for high-current performance
- Unprotected design for use in properly managed systems
Overview
The Efest IMR18650V1 is a high-output lithium-ion battery engineered for applications that require strong, consistent current delivery. With a nominal capacity of 2500mAh and a 20A continuous discharge rating, this flat top 18650 cell provides dependable power in compact energy systems. Its IMR chemistry supports stable operation under demanding loads, making it well-suited for regulated battery packs and power-managed electronics.
Applications / Uses
- High-output flashlights and lighting systems
- Portable power banks and battery packs
- Power tools and regulated electronic equipment
- DIY and custom battery pack builds
- High-current electronic applications
SPECIFICATIONS
| Manufacturer: | Efest |
| Model: | IMR18650V1 |
| Battery Size: | 18650 |
| Positive Terminal: | Flat Top |
| Nominal Capacity: | 2500mAh |
| Continuous Discharge Rating: | 20A |
| Nominal Voltage: | 3.7V |
| Maximum Voltage: | 4.2V |
| Cut-off Voltage: | 2.5V |
| Protected: | No, unprotected |
| Rechargeable: | Yes |
| Approx. Dimensions: | 18.42mm x 65.1mm |
| Approx. Weight: | 44.4g |
⚠ Important Safety Warnings
Improper handling or misuse of this lithium-ion battery can result in FIRE, EXPLOSION, or THERMAL RUNAWAY, causing personal injury, property damage, or death. Users must read and follow all safety guidelines before purchase and use. Click here to review the full safety guidelines.
- Critical Warning: Never carry loose batteries in your pocket, purse, or bag. Loose batteries can come into contact with metal objects like keys or coins, causing a short circuit, which may result in severe burns, fire, or explosion. Always store or transport batteries in a protective case.
- Intended Use: This battery is designed for integration into protected battery packs with a Battery Management System (BMS) or Protection Circuit Board (PCB). It is not intended for standalone use or for e-cigarettes, vaporizers, or similar devices.
-
Thermal Runaway: A chain reaction where heat from a failing battery
causes further overheating, potentially leading to fire or explosion.
- Causes: Overcharging, short circuits, physical damage, or exposure to high temperatures.
- Prevention: Use a smart charger, avoid damage, and store batteries in a cool, dry place.
- Storage & Transport: Always store batteries in protective cases to prevent accidental contact with metal objects. Never store loose batteries in pockets, purses, bags, or near conductive materials.
- Inspection: Do not use if the PVC wrapper, terminal insulator, or casing is damaged, dented, leaking, or bulging. Continued use could result in failure, fire, or explosion.
- Charging: Use a smart charger specifically designed for lithium-ion batteries and ensure the charger's voltage matches the battery's specifications. Never overcharge, over-discharge, or leave unattended while charging.
-
Prohibited Activities:
- Do not expose the battery to extreme heat, fire, or liquids.
- Do not short circuit, puncture, crush, or modify the battery.
- Do not charge or discharge beyond the manufacturer’s voltage range.
- Do not dispose of in regular trash—always recycle at approved facilities.
- Emergency Response: If the battery overheats, emits smoke, or swells, move it to a non-flammable surface (e.g., sand or concrete) and stop use immediately. In case of fire, use a Class D fire extinguisher or sand. Do not use water.
