Description
Introducing the Panasonic NCR18650BD, a high-capacity lithium-ion battery designed for demanding applications that require both high energy and high discharge rates. With a typical capacity of 3180mAh and a maximum discharge current of 10A, this battery is perfectly suited for high-performance devices such as power tools, portable devices, and electric vehicles. Its advanced CC-CV charging method ensures optimal performance and longevity, while the robust build quality supports operation in a wide range of temperatures.
- High Capacity: Offers a typical capacity of 3180mAh for long-lasting energy supply in demanding electronic devices.
- High Discharge Rate: Capable of a 10A continuous discharge rate, making it ideal for high-performance applications.
- Optimal Charging Technology: Utilizes a Constant Current-Constant Voltage (CC-CV) charging method to maximize battery life and efficiency.
- Wide Temperature Range: Operates effectively in a broad temperature range from -20 to +60°C, suitable for use in various environmental conditions.
- Energy Efficient: Delivers excellent energy density with 630 Wh/l volumetric and 217 Wh/kg gravimetric, ensuring high power in a compact size.
SPECIFICATIONS
| Manufacturer: | Panasonic |
| Model: | NCR18650BD |
| Size: | 18650 |
| Positive Terminal: | Flat Top |
| Nominal Capacity: | 3180mAh |
| Continuous Discharge Rating (max): | 10A Maximum Continuous |
| Nominal Voltage: | 3.6V |
| Maximum Voltage: | 4.2V |
| Discharge cut-off Voltage: | 2.5V |
| Protected: | NO, UNPROTECTED. |
| Rechargeable: | Yes |
| Approx. Dimensions: | 18.20mm x 65mm |
| Approx. Weight: | 46.4g |
| Country of Origin: | Japan |
| Data Specification Sheet: | Panasonic NCR18650BD Datasheet |
⚠ Important Safety Warnings
Improper handling or misuse of this lithium-ion battery can result in FIRE, EXPLOSION, or THERMAL RUNAWAY, causing personal injury, property damage, or death. Users must read and follow all safety guidelines before purchase and use. Click here to review the full safety guidelines.
- Critical Warning: Never carry loose batteries in your pocket, purse, or bag. Loose batteries can come into contact with metal objects like keys or coins, causing a short circuit, which may result in severe burns, fire, or explosion. Always store or transport batteries in a protective case.
- Intended Use: This battery is designed for integration into protected battery packs with a Battery Management System (BMS) or Protection Circuit Board (PCB). It is not intended for standalone use or for e-cigarettes, vaporizers, or similar devices.
-
Thermal Runaway: A chain reaction where heat from a failing battery
causes further overheating, potentially leading to fire or explosion.
- Causes: Overcharging, short circuits, physical damage, or exposure to high temperatures.
- Prevention: Use a smart charger, avoid damage, and store batteries in a cool, dry place.
- Storage & Transport: Always store batteries in protective cases to prevent accidental contact with metal objects. Never store loose batteries in pockets, purses, bags, or near conductive materials.
- Inspection: Do not use if the PVC wrapper, terminal insulator, or casing is damaged, dented, leaking, or bulging. Continued use could result in failure, fire, or explosion.
- Charging: Use a smart charger specifically designed for lithium-ion batteries and ensure the charger's voltage matches the battery's specifications. Never overcharge, over-discharge, or leave unattended while charging.
-
Prohibited Activities:
- Do not expose the battery to extreme heat, fire, or liquids.
- Do not short circuit, puncture, crush, or modify the battery.
- Do not charge or discharge beyond the manufacturer’s voltage range.
- Do not dispose of in regular trash—always recycle at approved facilities.
- Emergency Response: If the battery overheats, emits smoke, or swells, move it to a non-flammable surface (e.g., sand or concrete) and stop use immediately. In case of fire, use a Class D fire extinguisher or sand. Do not use water.
Disclaimer
18650Battery.com is not responsible for any damages, injuries, or claims arising from improper use, handling, or failure to follow these safety guidelines. Lithium-ion batteries require strict adherence to all safety protocols. It is the reseller's responsibility to ensure all safety warnings and product guidelines are effectively communicated to customers. Users and resellers assume full responsibility for the safe handling, usage, and distribution of this product.
