Key Features
- 25A max continuous discharge for high-drain performance
- Large 5000mAh capacity for extended runtime
- Rated for 500+ charge cycles for long service life
- Built-in explosion-proof safety valve
- Gold-plated protection circuit enhances reliability
Note: This is a button top protected 21700 battery which is longer than a standard flat top unprotected 21700 battery.
Overview
The XTAR 3.6V 21700HP 5000mAh Lithium Battery is engineered for high-demand electronics requiring strong, stable output. With a 25A continuous discharge rating, advanced internal safety features, and a highly durable protection circuit, this cell delivers exceptional capacity and reliable power for professional-grade devices.
Applications / Uses
- High-drain LED flashlights
- Professional lighting tools
- Portable equipment needing long runtime
- High-performance electronics
- Specialty and hobby applications
SPECIFICATIONS
| Nominal Capacity | 5000mAh |
| Minimum Capacity | 4800mAh |
| Nominal Voltage | 3.6V |
| Discharge Cutoff Voltage | 2.5V |
| Max Continuous Discharge | 25A (≤80℃) |
| Internal Resistance | ≤23mΩ |
| Cycle Life | 500+ |
| Charging Voltage | 4.2±0.03V |
| Standard / Max Charging Current | 2.5A / 5A |
| Discharge Overcurrent Protection | 25.5–35A |
| Transport Voltage | 3.6–3.9V |
| Protected | Yes |
| Positive Terminal | Button Top |
| Operating Temperature | -20 to 50℃ |
| Storage Temperature | -20 to 50℃ (Best ≤25℃) |
| Dimensions | φ21.5±0.3 × H70.5±0.3 mm |
| Net Weight | ≤73g |
| Data Specification Sheet: | XTAR 3.6V 21700HP 5000mAh 25A Lithium battery Datasheet |
⚠ Important Safety Warnings
While this battery is equipped with built-in protection circuitry to help prevent overcharging, over-discharging, and short circuits, improper handling or misuse can still result in FIRE, EXPLOSION, or THERMAL RUNAWAY, causing personal injury or property damage. Users must read and follow all safety guidelines before purchase and use. Click here to review the full safety guidelines.
- Intended Use: This battery is designed for use in flashlights, headlamps, and similar devices that require a button top configuration. Ensure compatibility with your device before use.
- Protection Circuit Limitations: While the protection circuit provides additional safety, it cannot prevent damage caused by misuse, including exposure to liquids, extreme heat, or physical damage.
- Storage & Transport: Always store batteries in protective cases to prevent accidental contact with metal objects (e.g., keys, coins, tools) that can cause a short circuit. Do not store loose batteries in pockets, bags, or other uncontrolled environments.
- Inspection: Do not use if the battery is dented, leaking, bulging, or if the outer wrapper or button top is damaged.
- Charging: Use a smart charger specifically designed for button top protected batteries. Do not exceed the battery's voltage and current specifications. Never leave the battery unattended while charging.
-
Prohibited Activities:
- Do not expose the battery to water, fire, or high heat.
- Do not modify, puncture, crush, or attempt to disassemble the battery.
- Do not use the battery if it becomes unusually hot during use or charging.
- Emergency Response: If a cell shows signs of thermal runaway (e.g., smoke, swelling, hissing, or heat), stop use immediately and, if it can be done safely, move it to a non-flammable surface (e.g., concrete or sand) away from combustible materials. Lithium-ion cells burn as Class B fires — use an ABC / dry-chemical fire extinguisher, or douse with large amounts of water to cool the cell and prevent the fire from spreading. Do not rely on a small spray; thorough cooling is required, and cells can reignite from residual heat, so monitor the area afterward. (Class D extinguishers are intended for lithium-metal batteries, not lithium-ion.) For any fire beyond a single small cell, evacuate and call emergency services.
Disclaimer
18650Battery.com is not responsible for any damages, injuries, or claims arising from improper use, handling, or failure to follow these safety guidelines. Lithium-ion batteries require strict adherence to all safety protocols. It is the reseller's responsibility to ensure all safety warnings and product guidelines are effectively communicated to customers. Users and resellers assume full responsibility for the safe handling, usage, and distribution of this product.
